Model: 7.0" IPS 1024*600 Mipi 30pin 280cd/m2 Full View TFT LCD Module
Specification:
Model NO.: | RB070D30N01A |
Screen Size: | 7.0" |
Resolution: | 1024*600 |
Module size(W*H*T): | 164*97*2.6mm |
Active area (W*H): | 154.21*85.92mm |
Controller: | HX8282-A&HX8696-A |
Brightness: | 21 White LED /300 cd/m² |
Display Type: | 16.7M COLORS |
Operating Temperature: | -20 ~ 70ºC |
Interface: | MIPI-DSI,FPC 30PIN,Pitch:0.5mm |
Ronbo Electronics Ltd., located at Dongguan, China, is one of the leading display suppliers. Its production line includes small to medium size LCD, TFT, and OLED modules for a variety of industrial and consumable application. We are one of the leading display providers of monochrome character LCD modules, graphic LCD modules, alphanumeric LCD panel & TFT modules. High-quality LCD modules are made based on our experienced engineering knowledge, well-managed supply chain.
Besides standard modules, our experience R&D staff can either support you value-added program or make customized product according to your specification
Moreover, our company has passed ISO 9001, ISO14001 certifications as well as RoHS.
Our website is http://www.ronboe.com
