TFT LCD Display

1_TFT LCD Display_横幅.jpg

     TFT LCD Displays are available in various sizes from 1.22"  to 15.0" TFT LCD.  they are including options of TFT panel, TFT LCM with controller board, color LCD module, and wide operating temperatures of -20°C to  70°C or -30°C to  80°C.
     They are available in various graphic display resolutions including QVGA (240 x 320), WQVGA (480x272),WVGA (800x480), 1024x600, XGA (1024x768), WXGA(1280x800) and son on.  and there are various interface available including MCU, RGB, TTL, LVDS, MIPI and so on.

     These LCD Displays are options of bonding with Resistive or Capacitive touch Screen using OCA or Double Tape, and are options of Driver Board and assistant funtion samples.

     The list below is our standard offering, please click into detail informaiton. However, We have many more customized solution and special sizes available as options. Please contact us for more information.

Image Size Model No Resolution Module size
(W*H*Tmm)
Active Area
(W*Hmm)
Controller IC Brightness Display Type Interface
5.0" RB050D50N329A 480*854 65.26*119.3*1.67 61.56*109.53 JD9161 400cd/m² TN, 12H RGB, FPC 50PIN, Pitch:0.5
5.0" RB050M20N373A 480*854 65.26*118.9*2.05 62.06*110.42 GC9503V 500cd/m² TN, 12H MIPI, FPC 20Pin, Pitch:0.8
7.0" RB070D39N02A 720*1280 91.2*164*2.45 86.94*154.56 TBD 18 White LED 350 cd/m² 16.7M MIPI-DSI, FPC 39PIN Pitch:0.3mm
7.0" RB070D40N04A 1024*600 164.9*100*2.5 153.6*90.0 NT51018 18 White LED 250cd/m² 16.7M COLORS MIPI-DSI, FPC 40PIN Pitch:0.5mm
7.0" RB070D50N06A 1024*600 163.8*97.0*2.6 154.21*85.92 HX8282-A&HX8696-A 24 White LED 290cd/m² 16.7M RGB 24Bit, FPC 50PIN Pitch:0.5mm
7.0" RB070D40N08A 800*480 164.9*100*3.3 153.6*86.64 HX8264 HX8664 21 White LED 290cd/m² 16.7M RGB 24Bit, FPC 40PIN Pitch:0.5mm
7.0" RB070D50N09A 800*480 164.9*100*3.5 154.08*85.92 EK9716/EK73002 21 White LED 290cd/m² 16.7M RGB 24Bit, FPC 50PIN Pitch:0.5mm
7.0" RB070D40N10A 1024*600 163.8*97.0*2.6 154.21*85.92 HX8282-A&HX8696-A 18 White LED 280cd/m² 16.7M MIPI interface, FPC 40PIN Pitch:0.5mm
7.0" RB070D50N11A 1024*600 165.0*100*3.5 154.21*85.92 TBD 18 White LED 250cd/m² 16.7M RGB 24Bit, FPC 50PIN Pitch:0.5mm
7.0" RB070D50N12A 1024*600 163.6*96.8*2.6 154.21*85.92 TBD 24 White LED 400cd/m² 16.7M RGB 24Bit, FPC 50PIN Pitch:0.5mm
7.0" RB070D40N13A 800*480 164.9*100*3.3 154.21*85.92 EK73002A/EK9713CA 14 White LED 200cd/m² 16.7M RGB 24Bit FPC 40PIN Pitch:0.5mm
8.0" RB080D50N02A 800*480 192.8*116.9*6.4 176.64*99.36 - 450cd/m² TN, 12H RGB 24Bit,FPC 50PIN, Pitch:0.5
8.0" RB080D50N03A 800*600 183.0*141.0*5.6 162.0*121.5 - 300cd/m² TN, 12H RGB 24Bit,FPC 50PIN, Pitch:0.5
8.0" ZJ080NA-08A 1024*600 192.8*116.9*6.4 176.64*99.36 - 500cd/m² TN, 12H LVDS,FPC 40PIN, Pitch:0.5
9.0" RB090D50N02A 1024*600 210.7*126.4*3.5 196.61*114.15 - 250cd/m² TN, 12H RGB,FPC 50Pin, Pitch:0.5
10.1" RB101D50N06A 1024*600 235.0*143.0*4.9 222.72*125.28 - 350cd/m² TN, 12H RGB 50PIN, Connector Pitch:0.5
10.1" RB101D50N04A 1024*600 235.0*143.0*2.8 222.72*125.28 - 250cd/m² TN, 12H RGB 50PIN, Connector Pitch:0.5
10.1" RB101D50N05A 1024*600 235.0*143.0*5.2 222.72*125.28 39 White LED 380cd/m² 16.7M COLORS RGB 24Bit FPC 50PIN P0.5
10.1" RB101L40N09A 1024*600 235.0*143.0*5.1 222.72*125.28 - 350cd/m² TN, 12H LVDS 40PIN, Connector Pitch:0.5
